70L/min yellow bilge pump
12V/24V 1100GPH Submersible Caravan Campervan Camp Marine Grade Water yellow Bilge Pump 1100GPH for grey water system
  • Brand:

    Singflo
  • Item No.:

    BL2512S
  • Shipping Port:

    Xiamen,Ningbo,Fuzhou,Shenzhen,Shandong,Shanghai etc.any port in China
  • Lead Time:

    7-20days
  • Payment:

    T/T, B/L,Paypal,western union etc.
Inquire
  • Product Details

Electric submersible bilge pump is suitable for all kinds of boat water supply and drainage,even for those who have a dc 12v power supply in rural aquaculture for human water supply. Such as water the flowers,poured food,wegetables and irrigation,etc.

This product saves electricity and has a low noise,large displacement,economic and is practical.

Advantage of yellow bilge pump

1.Large delivery volume,high delivery pressure,aimed the maximum of this class!

2.Continuous running in the water all right!

  Unique motor cooling system enables continuous running.

3.Double mechanical seal system equipped guarantees the complete shaft sealing.

4.Useing 304 Stalinless,saltwater-proof aluminum alloy, anti shock PBT plastics assure long durability,perfect against saltwater corrosion.

5.Small size, light,compact,easy to handle.

6.Strainer can be quickly removed without tool,makes easy to clean iinside.

7.In case using elbow,can fix hose in any directions flexibly without bending hose.



Application of electric 1100GPH bilge pump

1.Pumping out water from ice

2.Pumping fresh water in preserve

3.Discharging of Bilge water

4.Emergency pumping on the boat

5.Washing on the deck

6.Water exchanging in fish farm

7.For camping use

8.Car washing



Technical Data of submersible bilge pump

 Model HYBL2512S HYBL2524S
 Outlet dia 25m(1'') 25mm (1'')
 Delivery volume 70L/min,18.5U.S.G/min 70L/min,18.5U.S.G/min
Delivery head 4m 4m
Water temp. 0-60degree C. 0-60 degree C.
Power DC-12V DC-24V
Current 5.4A 2.5A
Rating Continuous Continuous
Motor power 45W/5400rpm 45W/5400rpm
Weight 1.3KGS 1.3KGS
Standard Accessory Elbow 1 Elbow 1

Dimension of bilge pump

DC submersible bilge pump

WIRING DIAGRAM of water bilge pump

wire of dc boat bilge pump
